Name: STC80 Zoomlion Used Truck Cranes 80ton Second Hand Truck Cranes For Sale
Brand: Zoomlion
Price: 1 USD

Brand Name : Zoomlion

Model Number : STC80

Certification : CE, ISO9001

Place of Origin : China

MOQ : 1

Price : Negotiable

Payment Terms : L/C, T/T

Delivery Time : 5-7 Days

Packaging Details : Bulk

Status : Used

Max. Lifting Height : 12.9 - 65m

Max. Lifting Weight : 80ton

Axle No. : 4

Jib boom : 2 Section

Production date : 2014

Contact Now

Used Zoomlion Truck Crane Zoomlion STC80 Second Hand Truck Mobile Crane

Production Details:

Model No.	STC80	Boom Type	Telescopic
Max. Rated Lifting Capacity	80000 kg	Max. Lifting Height of Jib	50m
Max Gradeability	44%	Working Diameter	24m
Transport Package	Complies with Min. export packaging requirements	Specification	15290×2400×3210mm
Driving Mileage	120000M	Working hours	12000h
Trademark	Zoomlion	Place of Origin	China
HS Code		Supply Capacity	10 Units/ Month

1. High energy efficiency--new 80tons mobile truck crane

5 sections U-shaped main boom, with large cross-section, the full length of the boom is 50meters;
Brand new 2.8meters wide chassis, heightened and widened rectangular section frame, enhanced torsional and bending resistance of hoisting load;
Adopt high horsepower 12L engine, 10 speed gearbox with synchronizer, heavy duty axle;
The max. grade is 44%, the fuel consumption/100 km is 44L.

2. Energy-saving and high efficiency hydraulic system

Good brand oil pump, hoisting motor configuration, to meet the requirements of precision hoisting: the Min. stable speed of rotation is 0.1°/s, and the Min. stable speed of hoisting is 1.5meters per minute;
Compared with the hydraulic control system, the electronic control system saves 15% of the overall energy saving when hoisting on the truck, and the heavy-load operation efficiency increases by 30%;

3. Comfortable, safe operating experience

The 0-20° widened and tiltable control space makes working at heights more comfortable and safer;
Remote-control operation Counterweight, mechanical structure mounting, do not need to unload for short-way transportation, reliable and safe;
The boarding shed is simplified, the maintenance is easy, and use is more convenient.

Product Parameters:

Overall length of the whole machine	15290mm
Overall width of the whole machine	2800mm
Overall height of the whole machine	3880mm
Engine max. power	276/1900Kw/rpm
Engine max. output torque	1800/1000-1400N.m/rpm
Top speed	80Km/h
Min. turning radius	12m
Approach angle	≥10°
Departure angle	≥14°
Max. gradeability	44%
Oil consumption per 100 km	≤44L
Max. rated lifting capacity	80t
Turntable tail turning radius	4.385m
max. load moment - Basic Arm	3293kN.m
max. load moment - Longest Main Boom	1803kN.m
Outrigger span (horizontal × vertical)	8×6.43m
Boom Length - Basic Boom	12.96m
Boom Length - Longest Main Boom	50m
Boom length - longest main boom + jib	67.5m
Main hoist single rope max. speed (no load)	130m/min
Max. speed of the auxiliary hoist single rope (no load)	130m/min
Boom full extension/retraction time	140s/160s
Boom full up/down time	65s/90s
Swing speed	0 ～ 1.8r/min
The total mass of the whole machine	50000
Axle load - one and two axle loads	24000kg
Axle load - three and four axle loads	26000kg
